   REDUKCIJA PE100:

REDUKCIJA PE100REDUKCIJA PE100

REDUKCIJA PE100

Brizgani ili injektirani fiting
HDPE100+ Polietilenski fiting za plin i vodu
Standard: TS EN 1555-3:2010 + A 1 • TS EN 12201-3 + A 1

d1-d2 Artikal Bar Z L L1 e1 e2 Težina (kg) Pak (kom)
Ø32-20 RD001600322011 PN16 125 55 54 3 2 0.027 150
Ø32-25 RD001600322511 PN16 125 58 54 3 2.3 0.039 150
Ø40-20 RD001600402011 PN16 150 73 57 3.7 2 0.040 100
Ø40-25 RD001600402511 PN16 148 72.9 55 3.7 2.3 0.051 80
Ø40-32 RD001600403211 PN16 140 70 50 3.7 3 0.057 80
Ø50-20 RD001600502011 PN16 110 45 45 4.6 2 0.070 75
Ø50-25 RD001600502511 PN16 152 71 54 4.6 2.3 0.072 80
Ø50-32 RD001600503211 PN16 153 71 52 4.6 3 0.072 80
Ø50-40 RD001600504011 PN16 150 70 52 4.6 3.7 0.083 70
Ø63-20 RD001600632011 PN16 120 50 45 5.8 2 0.082 50
Ø63-25 RD001600632511 PN16 151 63 52 5.8 2.3 0.085 50
Ø63-32 RD001600633211 PN16 151 63 52 5.8 3 0.091 50
Ø63-40 RD001600634011 PN16 151 62 57 5.8 3.7 0.101 50
Ø63-50 RD001600635011 PN16 115 50 45 5.8 4.6 0.118 50
Ø75-32 RD001600753211 PN16 172 70 57 6.8 3 0.139 35
Ø75-40 RD001600754011 PN16 173 69 65 6.8 3.7 0.149 35
Ø75-50 RD001600755011 PN16 172 70 64 6.8 4.6 0.176 35
Ø75-63 RD001600756311 PN16 170 69 67 6.8 5.8 0.195 25
Ø90-32 RD001600903211 PN16 185 71 48 8.2 3 0.250 25
RD001600903212 PN10 180 75 55 5.4 2.6 0.197 25
Ø90-40 RD001600904011 PN16 190 80 55 8.2 3.7 0.184 20
RD001600904011 PN10 180 75 55 5.4 2.6 0.280 20
Ø90-50 RD001600905011 PN16 186 72 54 8.2 4.6 0.24 20
RD001600905011 PN10 187 81 60 5.4 3.2 0.186
Ø90-63 RD001600906311 PN16 197 80 63 8.2 5.8 0.289 22
RD001600906311 PN10 185 75 58 5.4 3.8 0.235 22
Ø90-75 RD001600907511 PN16 181 77 64 8.2 6.8 0.311 20
RD001600907511 PN10 184 82 62 5.4 0.265 20
Ø110-32 RD001601103211 PN16 200 75 50 10 3 0.328 14
RD001001103211 PN10 200 75 50 6.6 0.291 14
Ø110-40 RD001601104011 PN16 200 75 50 10 3.7 0.296 14
RD001001104011 PN10 200 75 50 6.6 0.280 14
Ø110-50 RD001601105011 PN16 200 75 55 10 4.6 0.41 14
RD001001105011 PN10 200 75 55 6.6 3.2 0.320 14
Ø110-63 RD001601106311 PN16 199 73 59 10 5.8 0.47 10
RD001001106311 PN10 199 73 59 6.6 3.8 0.328 10
Ø110-75 RD001601107511 PN16 199 73 59 10 6.8 0.495 10
RD001001107511 PN10 199 73 59 6.6 4.5 0.392 10
Ø110-90 RD001601109011 PN16 200 80 60 10 8.2 0.53 10
RD001001109011 PN10 200 80 60 6.6 5.4 0.428 10
Ø125-50 RD001601255011 PN16 200 80 60 11.4 4.6 0.474 24
RD001001255011 PN10 200 80 60 7.4 3.2 0.43 24
Ø125-63 RD001601256311 PN16 202 79 58 11.4 5.8 0.545 24
RD001001256311 PN10 200 77 60 7.4 3.8 0.46 24
Ø125-75 RD001601257511 PN16 200 80 72 11.4 6.8 0.56 24
RD001001257511 PN10 200 80 72 7.4 4.5 0.41 24
Ø125-90 RD001601259011 PN16 202 79 75 11.4 8.2 0.649 24
RD001001259011 PN10 210 90 80 7.4 5.4 0.46 24
Ø125-110 RD001612511011 PN16 198 79 71 11.4 10 0.721 16
RD001012511011 PN10 210 80 85 7.4 6.6 0.59 16
Ø140-50 RD001601405011 PN16 225 85 72 12.7 4.6 0.632 12
RD001001405011 PN10 225 85 75 8.3 3 0.475 12
Ø140-63 RD001601406311 PN16 220 85 75 12.7 5.8 0.678 11
RD001001406311 PN10 220 85 75 8.3 3.8 0.5 11
Ø140-75 RD001601407511 PN16 223 79 72 12.7 6.8 0.754 11
RD001001407511 PN10 223 79 72 8.3 4.5 0.567 11
Ø140-90 RD001601409011 PN16 220 93 83 12.7 8.2 0.94 9
RD001001409011 PN10 220 93 83 8.3 5.4 0.72 9
Ø140-110 RD001614011011 PN16 215 95 75 12.7 10 0.925 9
RD001014011011 PN10 215 95 75 8.3 6.6 0.741 9
Ø140-125 RD001614012511 PN16 221 96 91 12.7 11.4 1.04 9
RD001014012511 PN10 221 96 91 8.3 7.4 0.79 9
Ø160-50 RD001601605011 PN16 235 90 75 14.6 4.6 1.29 10
RD001001605011 PN10 235 90 75 9.5 3 1.24 10
Ø160-63 RD001601606311 PN16 220 90 70 14.6 5.8 1.37 9
RD001001606311 PN10 220 90 70 9.5 3.8 0.960 9
Ø160-75 RD001601607511 PN16 220 90 70 14.6 6.8 0.882 9
RD001001607511 PN10 220 90 70 9.5 4.5 0.766 9
Ø160-90 RD001601609011 PN16 236 92 75 14.6 8.2 1.165 8
RD001001609011 PN10 236 92 75 9.5 5.4 0.875 8
Ø160-110 RD001616011011 PN16 230 98 87 14.6 10 0.846 8
RD001016011011 PN10 230 98 87 9.5 6.6 0.85 8
Ø160-125 RD001616012511 PN16 231 91 76 14.6 11.4 1.395 8
RD001016012511 PN10 231 91 76 9.5 7.4 1.02 8
Ø160-140 RD001616014011 PN16 250 100 90 14.6 12.7 1.46 8
RD001016014011 PN10 250 100 90 9.5 8.3 0.9 8
Ø180-63 RD001601806311 PN16 250 102 86 16.4 5.8 1.127 7
RD001001806311 PN10 250 102 86 10.7 3.8 1,105 7
Ø180-75 RD001601807511 PN16 250 105 77 16.4 6.8 1.244 7
RD001001807511 PN10 250 105 77 10.7 4.5 1,213 7
Ø180-90 RD001601809011 PN16 256 100 91 16.4 8.2 1.236 7
RD001001809011 PN10 256 100 91 10.7 5.4 0.822 7
Ø180-110 RD001618011011 PN16 252 98 95 16.4 10 1.38 7
RD001018011011 PN10 252 98 95 10.7 6.6 0.98 7
Ø180-125 RD001618012511 PN16 252 101 98 16.4 11.4 1.512 6
RD001018012511 PN10 252 101 98 10.7 7.4 1.094 6
Ø180-140 RD001618014011 PN16 249 104 93 16.4 12.7 1.724 6
RD001018014011 PN10 249 104 93 10.7 8.3 1.198 6
Ø180-160 RD001618016011 PN16 250 96 95 16.4 14.6 1.732 5
RD001018016011 PN10 250 96 95 10.7 9.5 1.278 5
Ø200-90 RD001602009011 PN16 250 105 90 18.2 8.2 1.735 5
RD001002009011 PN10 250 105 90 11.9 5.4 1.263 5
Ø200-110 RD001620011011 PN16 268 113 78 18.2 10 1.766 5
RD001020011011 PN10 268 113 78 11.9 6.6 1.42 5
Ø200-125 RD001620012511 PN16 266 124 84 18.2 11.4 2.005 5
RD001020012511 PN10 266 124 84 11.9 7.4 1.506 5
Ø200-140 RD001620014011 PN16 260 120 100 18.2 12.7 2.14 5
RD001020014011 PN10 260 120 100 11.9 8.3 1.593 5
Ø200-160 RD001620016011 PN16 265 115 100 18.2 14.6 2.198 5
RD001020016011 PN10 265 115 100 11.9 9,,5 1.76 5
Ø200-180 RD001620018011 PN16 270 125 105 18.2 16.4 2.67 5
RD001020018011 PN10 270 125 105 11.9 10.7 2.18 5
Ø225-90 RD001602259011 PN16 270 128 84 20.5 8.2 1,642 1
RD001002259011 PN10 270 128 84 13.4 5.4 2,422 1
Ø225-110 RD001622511011 PN16 270 123 84 20.5 10 2.383 1
RD001022511011 PN10 270 123 84 13.4 6.6 1.727 1
Ø225-125 RD001622512511 PN16 270 123 83 20.5 11.4 2.47 1
RD001022512511 PN10 270 123 83 13.4 7.4 1.729 1
Ø225-140 RD001622514011 PN16 270 123 88 20.5 12.7 2.576 1
RD001022514011 PN10 270 123 88 13.4 8.3 1.786 1
Ø225-160 RD001622516011 PN16 270 120 90 20.5 14.6 3.126 1
RD001022516011 PN10 270 120 90 13.4 9.5 1.74 1
Ø225-180 RD001622518011 PN16 270 124 98 20.5 16.4 2.972 1
RD001022518011 PN10 270 124 98 13.4 10.7 2.03 1
Ø225-200 RD001622520011 PN16 270 126 100 20.5 18.2 2,310 1
RD001022520011 PN10 270 126 100 13.4 11.9 2.38 1
Ø250-110 RD001625011011 PN16 275 119 111 22.7 10 3.125 1
RD001025011011 PN10 275 125 90 14.8 6.6 2.27 1
Ø250-125 RD001625012511 PN16 275 115 80 22.7 12.7 4.76 1
RD001025012511 PN10 275 115 80 14.8 7.4 3,198 1
Ø250-140 RD001625014011 PN16 275 125 90 22.7 12.7 2,334 1
RD001025014011 PN10 275 110 90 14.8 8.3 3,198 1
Ø250-160 RD001625016011 PN16 313 110 107 22.7 14.6 3.13 1
RD001025016011 PN10 313 110 107 14.8 9.5 1.742 1
Ø250-180 RD001625018011 PN16 315 124 111 22.7 16.4 3,892 1
RD001025018011 PN10 315 124 111 14.8 10.7 3,746 1
Ø250-200 RD001625020011 PN16 315 115 100 22.7 18.2 4.02 1
RD001025020011 PN10 315 115 100 14.8 11.9 2.923 1
Ø250-225 RD001625022511 PN16 315 125 120 22.7 20.5 4.76 1
RD001025022511 PN10 315 125 120 14.8 13.4 3.67 1
Ø280-110 RD001628011011 PN16 340 140 105 25.4 10 4.52 1
RD001028011011 PN10 340 140 105 16.6 6.6 3.28 1
Ø280-125 RD001628012511 PN16 340 140 105 25.4 11.4 4,524 1
RD001028012511 PN10 340 140 105 16.6 7.4 3,344 1
Ø280-140 RD001628014011 PN16 340 140 105 25.4 12.7 4,524 1
RD001028014011 PN10 340 140 105 16.6 8.3 3,344 1
Ø280-160 RD001628016011 PN16 340 140 105 25.4 14.6 5.054 1
RD001028016011 PN10 340 140 105 16.6 9.5 3.46 1
Ø280-180 RD001628018011 PN16 340 140 120 25.4 16.4 3,462 1
RD001028018011 PN10 340 140 120 16.6 10.7 5,058 1
Ø280-200 RD001628020011 PN16 340 142 120 25.4 18.2 5.56 1
RD001028020011 PN10 340 142 120 16.6 11.9 3.63 1
Ø280-225 RD001628022511 PN16 340 140 145 25.4 20.5 4,347 1
RD001028022511 PN10 340 140 145 16.6 13.4 3.82 1
Ø280-250 RD001628025011 PN16 340 135 125 25.4 22.7 7.09 1
RD001028025011 PN10 340 135 125 16.6 14.8 4.45 1
Ø315-160 RD001631516011 PN16 335 145 95 28.6 14.6 4.56 1
RD001031516011 PN10 335 145 95 18.7 9.5 4.56 1
Ø315-180 RD001631518011 PN16 335 145 110 28.6 16.4 4,236 1
RD001031518011 PN10 335 145 110 18.7 10.7 4.775 1
Ø315-200 RD001631520011 PN16 360 145 130 28.6 18.2 7.6 1
RD001031520011 PN10 360 145 130 18.7 11.9 5.17 1
Ø315-225 RD001631522511 PN16 360 145 110 28.6 20.5 7.13 1
RD001031522511 PN10 360 145 110 18.7 13.4 4,875 1
Ø315-250 RD001631525011 PN16 360 145 120 28.6 22.7 8.74 1
RD001031525011 PN10 360 145 120 18.7 14.8 5.15 1
Ø315-280 RD001631528011 PN16 360 145 130 28.6 25.4 7.565 1
RD001031528011 PN10 360 145 130 18.7 25.4 5.852 1
Ø355-160 RD001635516011 PN16 360 170 140 32.2 14.6 8,914 1
RD001035516011 PN10 360 170 140 21.1 9.5 5,378 1
Ø355-180 RD001635518011 PN16 360 170 140 32.2 16.4 8,914 1
RD001035518011 PN10 360 170 140 21.1 10.7 5,378 1
Ø355-200 RD001635520011 PN16 360 170 140 32.2 18.2 8.14 1
RD001035520011 PN10 360 170 140 21.1 11.9 5.26 1
Ø355-225 RD001635522511 PN16 360 170 140 32.2 20.5 8,914 1
RD001035522511 PN10 360 170 140 21.1 13.4 5,378 1
Ø355-250 RD001635525011 PN16 360 170 135 32.2 22.7 9.04 1
RD001035525011 PN10 360 170 135 21.1 14.8 5.96 1
Ø355-280 RD001635528011 PN16 360 172 145 32.2 25.4 10,341 1
RD001035528011 PN10 360 172 145 21.1 16.6 6.59 1
Ø355-315 RD001635531511 PN16 360 172 145 32.2 28.6 11.3 1
RD001035531511 PN10 360 172 145 21.1 21.1 10,460 1
Ø400-200 RD001640020011 PN16 375 175 110 36.3 18.2 9,400 1
RD001040020011 PN10 375 175 110 23.7 11.9 7.43 1
Ø400-250 RD001640025011 PN16 375 175 105 36.3 22.7 11.716 1
RD001040025011 PN10 375 175 105 23.7 14.8 8.18 1
Ø400-280 RD001640028011 PN16 375 175 105 36.3 25.4 11,432 1
RD001040028011 PN10 375 175 105 23.7 16.6 8.056 1
Ø400-315 RD001640031511 PN16 375 175 155 36.3 28.6 12.67 1
RD001040031511 PN10 375 175 155 23.7 18.7 8.31 1
Ø400-355 RD001640035511 PN16 375 175 155 36.3 32.2 13.808 1
RD001040035511 PN10 375 175 155 23.7 21.1 12.26 1
